2-Wire Current Square Output Differential Speed Sensor IC
SQ Interface,Fixed+Adaptive Hysteresis Type, 0~12kBW
AEC-Q100，ASIL-B，Zero-Speed Detection，PCB Less，Speed Detection
View all products >
1. Wheel Speed Sensor
Hot
SC9682TS
Hot
SC9682T2
2-Wire Current Square Output Differential Speed Sensor IC
SQ Interface,Fixed+Adaptive Hysteresis Type,0~12kHz BW, T2 Package
AEC-Q100，ASIL-BHot
SC9641TS-PC
2-Wire Current Square Output Differential Speed Sensor IC
SQ Interface,Fixed Hysteresis Type, 1~10kBW
AEC-Q100，Speed Detection，Integrated ceramic capacitorHot
SC9641TS
2-Wire Current Square Output Differential Speed Sensor IC
SQ Interface,Fixed Hysteresis Type, 1~10kBW
AEC-Q100，Speed DetectionHot
SC9683TS
2-Wire Current PWM Output T Differential Speed Sensor IC
PWM Interface,Fixed+Adaptive Hysteresis Type, 0~5kBW
AEC-Q100,ASIL-B,PCB Less,Speed+Direction DetectionHot
SC9683T2
2-Wire Current PWM Output T Differential Speed Sensor IC
PWM Interface,Fixed+Adaptive Hysteresis Type, 0~5kBW, T2 Package
AEC-Q100,ASIL-B,PCB Less,Speed+Direction DetectionHot
SC9642TS-EC
2-Wire Current PWM Output Differential Speed Sensor IC
PWM Interface, Fixed Hysteresis Type, 1~5kBW
AEC-Q100, Speed+Direction Detection, Integrated ceramic capacitorHot
SC9684T2
2-Wire Current AK Output Differential Speed Sensor IC
AK Interface,Fixed+Adaptive Hysteresis Type, 0~1.8kBW, T2 Package
AEC-Q100, ASIL-B, Vibration Suppression
View all products >
2. Camshaft Sensor
Hot
SC9388T3
3-Wire Voltage-Mode Phase-Programmable Camshaft Position Sensor IC
TPOS, MTP, Adaptive Hysteresis Type, 0~8KHz BW
AEC-Q100, ASIL-B, High Accuracy, PCB-less, Open DrainHot
SC9675IM
4-Wire Voltage-Mode Self-Calibrating Speed Sensor IC
TPOS, OTP, Adaptive Hysteresis Type, 0~8KHz BW
AEC-Q100, Back-Magnetic, Self-adjusting, Open Drain
SC9675T3
3-Wire Voltage-Mode Programmable True Power-On State Speed Sensor IC
TPOS, OTP, Adaptive Hysteresis Type, 0~8KHz BW
AEC-Q100, PCB Less, Open Drain
SC9314UA
AEC-Q100, Self-adjusting, Square Output
3-Wire Voltage-Mode Self-Calibrating Hall Effect Gear Sensor IC
Fixed Hysteresis Type, 0~20KHz BW
AEC-Q100, Self-adjusting, Square Output
View all products >
3. Crankshaft Sensor
Hot
SC9669T3
High Accuracy Programmable Crankshaft Position Sensor IC
PWM Interface, Adaptive Hysteresis Type, Speed+Dir, 0~12KHz BW
AEC-Q100, ASIL-B,High Accuracy, PCB-lessHot
SC9621VB
4-Wire Voltage, High-Accuracy Zero-Crossing Flip Differential Speed Sensor IC
SQ Interface, Fixed Hysteresis Type, Speed, 5~20KHz BW
AEC-Q100, Reverse protection, Zero-Crossing Flip/ Mid-Tooth FlipHot
SC9625VB
4-Wire Voltage,High-Accuracy Edge-Flip Differential Speed Sensor IC
SQ Interface, Speed, 5~20KHz BW
AEC-Q100, Output, Reverse protection, Tooth Edge Flip
View all products >
4. Transmission Sensor
Hot
SC9685TS-FP180
Two-Wire Current PWM Output Transmission Speed Sensor IC
Speed+Dir,180/45us Pulse Width, 0~12KHz BW
AEC-Q100, ASIL-B, Vibration Suppression, PCB-lessHot
SC9685TS-RP180
Two-Wire Current PWM Output Transmission Speed Sensor IC
Speed+Dir,45/180us Pulse Width, 0~12KHz BW
AEC-Q100, ASIL-B, Vibration Suppression, PCB-lessHot
SC9685TS-RP90
Two-Wire Current PWM Output Transmission Speed Sensor IC
Speed+Dir,45/90us Pulse Width, 0~12KHz BW
AEC-Q100, ASIL-B, Vibration Suppression, PCB-lessHot
SC9685TS-FP90
Two-Wire Current PWM Output Transmission Speed Sensor ICr IC
Speed+Dir,90/45us Pulse Width, 0~12KHz BW
AEC-Q100, ASIL-B, Vibration Suppression, PCB-lessHot
SC9685TS-RP120
Two-Wire Current PWM Output Transmission Speed Sensor IC
Speed+Dir,120/60us Pulse Width, 0~9KHz BW
AEC-Q100, ASIL-B, Vibration Suppression, PCB-lessHot
SC9686T3-FP90
Three-Wire Differential Transmission Speed Sensor IC with PWM Output
Speed+Dir,90/45us Pulse Width, 0~12KHz BW
AEC-Q100, ASIL-B, Vibration Suppression, PCB-lessHot
SC9686T3-FP180
Three-Wire Differential Transmission Speed Sensor IC with PWM Output
Speed+Dir,180/45us Pulse Width, 0~12KHz BW
AEC-Q100, ASIL-B, Vibration Suppression, PCB-lessHot
SC9625VB
4-Wire Voltage,High-Accuracy Edge-Flip Differential Speed Sensor IC
SQ Interface, Speed, 5~20KHz BW
AEC-Q100, Output, Reverse protection, Tooth Edge Flip
View all products >
5. Gear tooth Encoder
Hot
SC9633VB
Quadrature Output High-Sensitivity Speed Sensing IC
1.2mm Hall Spacing,A+B Interface,Fixed Hysteresis Type,10~20KHz BW
OVP，Reverse protection，High SensitivityHot
SC9632VB
Quadrature Output High-Sensitivity Speed Sensing IC
2.1mm Hall Spacing,A+B Interface,Fixed Hysteresis Type,10~20KHz BW
OVP，Reverse protection，High SensitivityHot
SC9634VB
Quadrature Output High-Sensitivity Speed Sensing IC
1.8mm Hall Spacing,A+B Interface,Fixed Hysteresis Type,10~20KHz BW
OVP，Reverse protection，High Sensitivity
