Programmable、High accuracy Camkshaft Position Sensor
TPOS、Phase-Programmable、3-wire Voltage-type Output
SC9388T3 is a non-contact, three-wire voltage-type camshaft position sensor IC based on Hall technology. It enables high-precision detection of camshaft phase, while supporting EOL (End-of-Line) programming and Auto-TPO functionality. With a phase accuracy of up to 0.1°, it meets the application requirements of engines compliant with new emission standards.
SC9388T3 Datasheet
Characteristics and advantages
phase accuracy：0.1°
64-Step Phase-Programmable
Jitter Suppression
Dynamic self-calibration principle
PCB-LESS
AEC-Q100 qualified
Suitable for special operating conditions of engines in hybrid and extended-range vehicles
Ordering Information
| Ordering Information | Marking | Ambient, TA(℃) | Package | Packing | Quantity |
|---|---|---|---|---|---|
| SC9388T3-TR-Q | 9388 | -40 ~ 150 | TS-3 | Tape & reel | 1500 /reel |
Product Application
Camshaft Phase Sensor
Documents and Resources
Semiment Product Selection Guide
SC9388T3 Datasheet
Application Note for SC9388T3
SC9388T3 is a non-contact, three-wire voltage-type camshaft position sensor IC based on Hall technology. It enables high-precision detection of camshaft phase, while supporting EOL (End-of-Line) programming and Auto-TPO functionality. With a phase accuracy of up to 0.1°, it meets the application requirements of engines compliant with new emission standards.
