Characteristics and advantages
Ultra-high sensitivity
High chopping frequency
Supports a wide voltage range：2.5~24V
Wide operating temperature range：-40~125℃
SC2202
High Sensitive Digital-Bipolar Hall Effect Sensor
Low Operating Voltage、Wide operating temperature range
The SC2202 is a Hall-effect latch designed in mixed signal BiCMOS technology. The device integrates a voltage regulator, Hall sensor with dynamic offset cancellation system, Schmitt trigger and an open-drain output driver, all in a single package. An onboard regulator permits with supply voltages of 2.5 to 24V which makes the device suitable for a wide range of industrial and automotive applications.
data table
SC2202 Datasheet
SC2202 Datasheet
Ordering Information
| Ordering Information | Mark | Option | Ambient, TA(℃) | Package | Packing | Quantity |
|---|---|---|---|---|---|---|
| SC2202SO-N-TR | 2202 | N | -40~125 | SOT23-3L | Reel | 3000/reel |
| SC2202UA-BK | 2202 | - | -40~125 | TO-92S | Bulk | 1000/bag |
Product Application
BLDC Commutation
Desk Lift Motor
BLDC Commutation, Motor Position Detection
Documents and Resources
Semiment Product Selection Guide
Selection Guide
English version
2025-10-22
SC2202 Datasheet
Datesheet
English version
2025-10-22
Application Note for SC2202
Application Note
video
The SC2202 is a Hall-effect latch designed in mixed signal BiCMOS technology. The device integrates a voltage regulator, Hall sensor with dynamic offset cancellation system, Schmitt trigger and an open-drain output driver, all in a single package. An onboard regulator permits with supply voltages of 2.5 to 24V which makes the device suitable for a wide range of industrial and automotive applications.
