Automotive-grade 40V-rated buck converter with 3.5A load capability
VE2430Q is a high-frequency synchronous buck converter featuring a compact design that delivers 3.5A continuous output current across a wide input voltage range (3.3V to 40V). It offers excellent load regulation, supports external clock synchronization, and features an ultra-low-power sleep mode. Achieving exceptional efficiency across a broad load range, it is suitable for diverse buck applications in automotive electronics and battery-powered systems.
VE2430Q Datasheet
Characteristics and advantages
Supports frequency dithering
AEC-Q100 Grade 1 certified
Input voltage range: 3.3V–40V
Load capacity: 3.5A
Ultra-low shutdown current: 2μA
Switching frequency: 350kHz–2.5MHz
Selectable operating modes: FCCM and DCM
Supports external clock synchronization
Package: QFN-16 (3mm × 4mm)
Ordering Information
| Ordering Information | Mark | Option | Class | Temperature Range | Package | Pack | Quantity |
|---|---|---|---|---|---|---|---|
| VE2430QI-ADJ-TR-Q | 2430Q | ADJ | Q | -40 to +125°C | FCQFN3x4-16 | TR | 5000 |
Product Application
ADAS Domain Controller
T-BOX
Cockpit Domain Controller
GNSS Module
Power Module
Documents and Resources
Semiment Product Selection Guide
VE2430Q Datasheet
Application Note for VE2430Q
VE2430Q is a high-frequency synchronous buck converter featuring a compact design that delivers 3.5A continuous output current across a wide input voltage range (3.3V to 40V). It offers excellent load regulation, supports external clock synchronization, and features an ultra-low-power sleep mode. Achieving exceptional efficiency across a broad load range, it is suitable for diverse buck applications in automotive electronics and battery-powered systems.
