Dual Channel Inductive Rotary Encoder IC
Non-magnetic, Non-contact Inductive Position Sensor Integrated Circuit
SC60370 is a non-magnetic, non-contact coil inductive position sensor IC. The Device uses the physical principle of eddy current to detect the position of a simple metal target moving above the coil, so as to measure the signal output. The SC60370 can be used for high-speed absolute position detection in automotive, industrial, medical and consumer applications.
SC60370 Datasheet
Characteristics and advantages
Utilizes coil induction sensing technology
Supports through-hole or end-cap mounting
Sine/cosine signal output
SPI communication interface
Internal EEPROM programmable functionality
Operating temperature range: -40°C to 125°C
QFN6x6 package
Ordering Information
| Ordering Information | Mark | Ambient(℃) | Package | Pack | Quantity |
|---|---|---|---|---|---|
| SC60370QS-TY | SC60370 | -40~125 | QFN6X6-40 | Tray | 140Pcs |
Product Application
Encoder Module
Documents and Resources
Semiment Product Selection Guide
SC60370 Datasheet
Application Note SC60370
SC60370 is a non-magnetic, non-contact coil inductive position sensor IC. The Device uses the physical principle of eddy current to detect the position of a simple metal target moving above the coil, so as to measure the signal output. The SC60370 can be used for high-speed absolute position detection in automotive, industrial, medical and consumer applications.
