Highly Integrated H-Bridge Driver Chip
DC Motor Driver
The ZH6200 is a 5V DC brushed motor driver capable of delivering a maximum continuous output current of 1.8A. It is primarily used in electronic locks, electronic tea sets, and electric toy motors.
ZH6200 Datasheet
Characteristics and advantages
Single-channel integrated power MOS full-bridge driver
Maximum continuous output current up to 1.8A, peak 2.5A
Over-temperature protection
Low on-resistance (0.2Ω)
Undervoltage protection, short-circuit protection, adaptive dead time
Drives forward, reverse, stop, and brake functions
Ordering Information
Product Application
Documents and Resources
Semiment Product Selection Guide
ZH6200 Datasheet
Application Note for ZH6200
The ZH6200 is a 5V DC brushed motor driver capable of delivering a maximum continuous output current of 1.8A. It is primarily used in electronic locks, electronic tea sets, and electric toy motors.
