High Accuracy Programmable Linear Output Hall Effect Sensor
BiCMOS、Open-circuit, over- and under- voltage detection
The SC468X is a BiCMOS programmable linear Hall Effect sensor IC. The linear output voltage is proportional to the magnetic flux density. The output voltage is proportional to the supply voltage. All the parameters of the SC468X transfer characteristic are fully programmable. The VQ, the sensitivity, the slope polarity, the output clamping levels, and the thermal sensitivity drift are all programmable in end-user applications.
SC4689SA Datasheet
Characteristics and advantages
AEC-Q100 qualified
Linear analog output voltage
Operates from 4.5 to 5.5 V supply voltage
Operates from -40 to 150℃ temperature range
Open-circuit, over- and under- voltage detection
EMC and ESD optimized design
Operate with static magnetic fields and dynamic Magnetic fields up to 2 kHz
Total error < 2% over temperature range
TO-92U, SOP8 package
Ordering Information
| Ordering Information | Package | Ambient (℃) | Mark | Pack |
|---|---|---|---|---|
| SC4688SA-BK-Q | TO-92U | -40℃~150℃ | 4688 | Bulk |
| SC4689SA-BK-Q | TO-92U | -40℃~150℃ | 4689 | Bulk |
| SC4688DC-TR-Q | SOP8 | -40℃~150℃ | 4688 | Tape&Reel |
| SC4688DA-TR-Q | SOP8 | -40℃~150℃ | 4688D | Tape&Reel |
Product Application
Electronic Accelerator Pedal
Documents and Resources
Semiment Product Selection Guide
SC4689SA Datasheet
Application Note for SC4689SA
The SC468X is a BiCMOS programmable linear Hall Effect sensor IC. The linear output voltage is proportional to the magnetic flux density. The output voltage is proportional to the supply voltage. All the parameters of the SC468X transfer characteristic are fully programmable. The VQ, the sensitivity, the slope polarity, the output clamping levels, and the thermal sensitivity drift are all programmable in end-user applications.
