Cost-effective Programmable linear output Hall-effect sensor
Angle detection、Overcurrent detection circuit、Low quiescent output voltage and sensitivity temperature drift
SC4616 is specifically engineered for applications including angle detection and DC current detection. The SC4616 provides a client-side calibration solution at no additional cost, and the programmable nature of the SC4616 allows it to compensate for installation errors in current sensing module assembly.
SC4616 Datasheet
Characteristics and advantages
Rail-to-rail output
Client-side calibration
Sensitivity range: 8mV/Gs~24mV/Gs
Low quiescent output voltage and sensitivity temperature drift
The output voltage and sensitivity vary little with the power supply
Wide ambient temperature range：-40℃~125°C
Resistant to mechanical stress
Undervoltage lockout
Package：TO-92S
Ordering Information
| Order Information | Marking | Ambient, TA(℃) | PKG | Packing | Quantity |
|---|---|---|---|---|---|
| SC4616UA-BK | 4616 | -40~125 | TO-92S | Bulk | 1000/bag |
Product Application
Hydraulic Cylinder Stroke Position
Documents and Resources
Semiment Product Selection Guide
SC4616 Datasheet
Application Note for SC4616
SC4616 is specifically engineered for applications including angle detection and DC current detection. The SC4616 provides a client-side calibration solution at no additional cost, and the programmable nature of the SC4616 allows it to compensate for installation errors in current sensing module assembly.
