Characteristics and advantages
AEC-Q100
Reverse battery protection: -28V
High chopping frequency
Supports a wide voltage range：-2.5V~24V
SC2432
High-performance digital Unipolar Hall effect sensor
High Voltage Withstand Reverse Polarity Protection、Multiple sensitivity ranges available
The SC243X family, produced with Bi-CMOS technology, is a chopper-stabilized Hall Effect Sensor that offers a magnetic sensing solution with superior sensitivity stability over temperature and integrated protection features.
data table
SC2432 Datasheet
SC2432 Datasheet
Ordering Information
| Ordering Information | Marking | Option | BOP(Gs) | BRP(Gs) | Ambient, TA(℃) | Package | Packing | Quantity |
|---|---|---|---|---|---|---|---|---|
| SC2430SO-TR | 2430 | S | +20 | +15 | -40~150 | SOT23-3L | Tape & Reel | 3000/Reel |
| SC2430UA-BK | 2430 | S | +20 | +15 | -40~150 | TO-92S | Bulk | 1000/Bulk |
| SC2432SO-TR | 2432 | S | +25 | +20 | -40~150 | SOT23-3L | Tape & Reel | 3000/Reel |
| SC2432SO-N-TR | 2432 | N | -25 | -20 | -40~150 | SOT23-3L | Tape & Reel | 3000/Reel |
| SC2432UA-BK | 2432 | S | +25 | +20 | -40~150 | TO-92S | Bulk | 1000/Bulk |
| SC2434SO-TR | 2434 | S | +70 | +55 | -40~150 | SOT23-3L | Tape & Reel | 3000/Reel |
| SC2434SO-N-TR | 2434 | N | -70 | -55 | -40~150 | SOT23-3L | Tape & Reel | 3000/Reel |
| SC2434UA-BK | 2434 | S | +70 | +55 | -40~150 | TO-92S | Bulk | 1000/Bulk |
| SC2436SO-TR | 2436 | S | +100 | +85 | -40~150 | SOT23-3L | Tape & Reel | 3000/Reel |
| SC2436UA-BK | 2436 | S | +100 | +85 | -40~150 | TO-92S | Bulk | 1000/Bulk |
| SC2438SO-TR | 2438 | S | +120 | +95 | -40~150 | SOT23-3L | Tape & Reel | 3000/Reel |
| SC2438UA-BK | 2438 | S | +120 | +95 | -40~150 | TO-92S | Bulk | 1000/Bulk |
Product Application
Center Console Open/Close
Center Console Movement
Electronic Steering Column Lock
Combination Switch
Switch Button Detection
Documents and Resources
Semiment Product Selection Guide
Selection Guide
English version
2025-10-22
SC2432 Datasheet
Datesheet
English version
2025-10-22
Application Note for SC2432
Application Note
SC2432
The SC243X family, produced with Bi-CMOS technology, is a chopper-stabilized Hall Effect Sensor that offers a magnetic sensing solution with superior sensitivity stability over temperature and integrated protection features.
