High Sensitivity Omnipolar Hall-effect Sensor
Reverse battery protection、AEC-Q100、Multiple sensitivity ranges available
The SC246X family, produced with BiCMOS technology, is a chopper-stabilized Hall Effect Sensor that offers a magnetic sensing solution with superior sensitivity stability over temperature and integrated protection features. An onboard regulator permits with supply voltages of 2.5 to 24V which makes the device suitable for a wide range of industrial and automotive applications
SC2464 Datasheet
Characteristics and advantages
Digital Omni-polar Hall-Effect sensor
Over-voltage protection at all pins
Supply operating range：2.5V~24V
Reverse battery protection (up to 28V)
Superior temperature stability
Robust EMC performance
Very high sensitivity
High chopping frequency
Ordering Information
| Ordering Information | Marking | Class | BOP(GS) | BRP(GS) | Ambient, (℃) | Package | Packing | Quantity |
|---|---|---|---|---|---|---|---|---|
| SC2462SO-TR | 2462 | ±25 | ±15 | -40~150 | SOT23-3L | TR | 3000/reel | |
| SC2462SO-TR-Q | 2462 | Q | ±25 | ±15 | -40~150 | SOT23-3L | TR | 3000/reel |
| SC2462UA-BK | 2462 | ±25 | ±15 | -40~150 | TO-92S | BK | 1000/bag | |
| SC2464SO-TR | 2464 | ±60 | ±50 | -40~150 | SOT23-3L | TR | 3000/reel | |
| SC2464UA-BK | 2464 | ±60 | ±50 | -40~150 | TO-92S | BK | 1000/bag | |
| SC2466SO-TR | 2466 | ±165 | ±135 | -40~150 | SOT23-3L | TR | 3000/reel |
Product Application
Position Detection
Roller Position Sensor
Documents and Resources
Semiment Product Selection Guide
SC2464 Datasheet
Application Note for SC2464
The SC246X family, produced with BiCMOS technology, is a chopper-stabilized Hall Effect Sensor that offers a magnetic sensing solution with superior sensitivity stability over temperature and integrated protection features. An onboard regulator permits with supply voltages of 2.5 to 24V which makes the device suitable for a wide range of industrial and automotive applications
