Characteristics and advantages
AEC-Q100 qualified
ISO26262 ASIL-B SEooC
Less than 20uA average current in micro-Power Mode
Reverse battery protection: -28V
Superior temperature stability
Wide voltage range：3V to 40V
SC2450-ML
3-Wire High Performance Programmable Switch Hall Effect Sensor
Micro Power、High Voltage、High Sensitivity、Omnipolar
The SC245X produced with BiCMOS technology, is a chopper-stabilized 3-wire Hall Effect Sensor that offers a magnetic sensing solution with superior sensitivity stability over temperature and integrated protection features. An onboard regulator permits with supply voltages of 3V to 40V, which makes the device suitable for a wide range of industrial and automotive applications. SC2450-L（BOP:±25Gs,BRP:±10Gs)
data table
SC2450-ML Datasheet
SC2450-ML Datasheet
Ordering Information
| Ordering Information | Marking | BOP(Gs) | BRP(GS) | Ambient, (℃) | Package | Packing | Quantity |
|---|---|---|---|---|---|---|---|
| SC2450SO-L-TR-Q | 2450 | ±25 | ±15 | -40~150 | SOT23-3L | TR | 3000/reel |
| SC2450SO-LI-TR-Q | 2450 | ±25 | ±15 | -40~150 | SOT23-3L | TR | 3000/reel |
| SC2450UA-L-BK-Q | 2450 | ±25 | ±15 | -40~150 | TO-92S | BK | 1000/bag |
| SC2450UA-LI-BK-Q | 2450 | ±25 | ±15 | -40~150 | TO-92S | BK | 1000/bag |
| SC2450SO-M-TR-Q | 2450 | ±25 | ±15 | -40~150 | SOT23-3L | TR | 3000/reel |
| SC2450UA-M-BK-Q | 2450 | ±25 | ±15 | -40~150 | TO-92S | BK | 1000/bag |
| SC2451SO-TR-Q | 2451 | +100 | +85 | -40~150 | SOT23-3L | TR | 3000/reel |
| SC2452SO-TR-Q | 2452 | +180 | +130 | -40~150 | SOT23-3L | TR | 3000/reel |
| SC2455SO-TR-Q | 2455 | +255 | +200 | -40~150 | SOT23-3L | TR | 3000/reel |
| SC2455UA-BK-Q | 2455 | +255 | +200 | -40~150 | TO-92S | BK | 1000/bag |
| SC2459SO-TR-Q | 2459 | Programmable | Programmable | -40~150 | SOT23-3L | TR | 3000/reel |
| SC2459UA-BK-Q | 2459 | Programmable | Programmable | -40~150 | TO-92S | BK | 1000/bag |
| SC2459SO-L-TR-Q | 2459 | Programmable | Programmable | -40~150 | SOT23-3L | TR | 3000/reel |
| SC2459UA-L-BK-Q | 2459 | Programmable | Programmable | -40~150 | TO-92S | BK | 1000/bag |
Product Application
Center Console Open/Close
Center Console Movement
Charging Port Cover Position Detection
