Rail to Rail Analog Output Linear Hall Sensor
Ultra-Wide Output Range、High-speed Linear Hall、High performance、Multi-Functional Linear Hall Effect Device
The SC4923 are high performance small versatile linear Hall-Effect devices which are operated by the magnetic field from a permanent magnet or an electromagnet. The radiometric output voltage is set by the supply voltage and varies in proportion to the strength of the magnetic. The quiescent output voltage of SC4923 is 90% of the supply voltage.
SC4923 Datasheet
Characteristics and advantages
Rail to rail analog output
The minimum operation voltage：2.5V
VDD=3.3V Sensitivity：3.3mV/GS for SC4923
Fast power-on time
High Linearity
Quiescent voltage output：90% of VCC for SC4923
Output voltage proportional to magnetic flux density
3-pin SIP and SOT23 package are available
Ordering Information
| Ordering Information | Sens(mV/Gs) | Ambient, TA(℃) | Package | Packing | Quantity |
|---|---|---|---|---|---|
| SC4901SO-N-TR | 1.65 | -40-125 | SOT23-3L | TR | 3000/reel |
| SC4901UA-BK | 1.65 | -40-125 | TO92S | BK | 1000/bag |
| SC4923SO-N-TR | 3.3 | -40-125 | SOT23-3L | TR | 3000/reel |
| SC4923UA-BK | 3.3 | -40-125 | TO92S | BK | 1000/bag |
| SC4903SO-N-TR | 3.3 | -40-125 | SOT23-3L | TR | 3000/reel |
| SC4903UA-BK | 3.3 | -40-125 | TO92S | BK | 1000/bag |
Product Application
Linear Keyboard
Hall Joystick
Linear Trigger
Documents and Resources
Semiment Product Selection Guide
SC4923 Datasheet
Application Note for SC4923
The SC4923 are high performance small versatile linear Hall-Effect devices which are operated by the magnetic field from a permanent magnet or an electromagnet. The radiometric output voltage is set by the supply voltage and varies in proportion to the strength of the magnetic. The quiescent output voltage of SC4923 is 90% of the supply voltage.
