Three-Wire Programable Crankshaft Position Sensor IC
Product Description
SC9669T3
Package: TS-3
The SC9669 produced by Bi-CMOS technology, it’s a chopper-stabilized & active differential Hall sensor ideally suited for crankshaft and transmission rotate detection applications. It have the auto-adjust function to keep the performance with high accuracy and low jitter capabilities.
Features & Benefits
AEC-Q100 qualified
ISO 26262 ASIL-B
Detect the speed and position of targets
Magnetic stray-field robustness due to differential Hall Sensing
Direction detection and Stop-Start-Algorithm
Vibration Suppression Algorithm
Temperature Compensation Algorithm
Customer-side Programming Enable
Programmable switching threshold for better accuracy
3-pin PCB-less TS-3 package
